VESSEL NAME
TRA234
TYPE
TRAWLER
CONVERSION(S)
-
HULL MATERIAL
-
FLAG
UKRAINE
PORT OF REGISTRY
-
BUILT YEAR
1986
BUILT PLACE
NIKOLAEV, OKEAN SHIPYARD, USSR
CLASSIFICATION
UKRAINE CLASS
CLASS NOTATION
KM(*) L1[1] AUT2 FISHING VESSEL
SS
01/14/2013
DD
-
LOA (M)
114.49
LOA BETWEEN MASTS (M)
-
LBP (M)
102.48
BEAM (M)
17.33
DEPTH (M)
11.40
SUMMER DRAFT (M)
6.64
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
6394.00
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
1918.00
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
2621.00
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
DISPLACEMENT (MT)
8066.00
LDT (MT)
5488.00
GEAR(S)
DERRICKS, 6 x 3.2MT
M/E(S)
2 x 6CHN 40/46, 3500BHP EACH, 520RPM
M/E POWER (KW)
2612
A/E(S)
2 x 8CHN 25/34-2, 600BHP EACH, 500RPM
GENERATOR(S)
2 x GMS 14-29-12, 400KW EACH, 400V
SHAFT GENERATOR(S)
2 x SBG 1600-1500, 1600KW EACH, 1500RPM, 400V
PROPELLER(S)
-
SPEED /CONSUMPTIONS
MAX 12KTS
WITH TRAWL FOR KRILL LOWERED, MAX 3.6KTS, MIN 2.6KTS
WITH TRAWL FOR FISH LOWERED, MAX 6KTS, MIN 4.8KTS
CONSUMPTION FOR 90% M/E LOAD: 20.2CBM/DAY
CONSUMPTION IN VOYAGE: 16.5CBM/DAY
FUEL TYPE
IFO120, MGO
BUNKER CAPACITY (CBM)
1642
TANKS CAPACITY (CBM)
BALLAST WATER: 739
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
4
CARGO CAPACITY (CBFT)
149037
CARGO CAPACITY (CBM)
4222
NUMBER OF FREEZING HOLDS
2
FREEZING HOLD CAPACITY (CBFT)
88885
FREEZING HOLD CAPACITY (CBM)
2518
COOLING SYSTEM
R12, R22
TEMPERATURE (℃)
-28/15/20
DECK(S)
-
WATERTIGHT BULKHEAD(S)
-
DECK EQUIPMENTS
WINCH ваерная 2 x WTI-12.5 (CARGO CAPACITY: 12.5MT)
WINCH кабельно-вытяжная 4 x VJ-10B (CARGO CAPACITY: 11MT)
WINCH гиневая 2 x WVJ-20 (CARGO CAPACITY: 23MT)
WINCH сетно-вытяжная 2 x ПЭ-96 (CARGO CAPACITY: 3.6MT) WINCH вспомогательная 2 x ПЭ-69 (CARGO CAPACITY: 1.8MT)
WINCH кабель зонда 1 x «Игла»
WINCH грузовая 4 x ПЭ-95 (CARGO CAPACITY: 3.6MT)
WINCH промыслово–грузовая 2 шт *ПЭ-65
FACTORY
FROZEN FISH: 25MT/24HRS
CANNED FISH: CAN NO. 6, 50000CANS/16HRS
CANNED KRILL: CAN NO. 1, 75000CANS/16HRS
FISH MEAL PLANT CAPACITY: 60-70MT RAW-FISH/24HRS
FISH-LIVER OIL
WATER MAKER
-
SEPARATORS
-
BOILER(S)
-
SAFTY EQUIPMENTS
-
ELECTRONICS
-
INSURANCE
-
CREW
110
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
USD 6.8 MILLION
REMARK(S)
AUTONOMY: 70DAYS
FISH MEAL HOLD: 1 x 188CBM
CANS STORAGE ROOM: 1 x 1516CBM
