VESSEL NAME
REF582
TYPE
REEFER CARRIER
DEEP FREEZING OR NOT
NO
FLAG
RUSSIA
PORT OF REGISTRY
MURMANSK
BUILT YEAR
1991
BUILT PLACE
KLAIPEDA, LITHUANIA
CLASSIFICATION
RS
CLASS NOTATION
KM(*) Ice1 Ice2 (at d<=4.04 m) [1]
SS
2028-05
DD
2026-05
LOA (M)
85.06
LBP (M)
75.25
BEAM (M)
13.34
DEPTH (M)
6.5
SUMMER DRAFT (M)
4.3
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
2383
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
714
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
1238
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
LDT (MT)
1728
DISPLACEMENT (MT)
3085
GEAR(S)
1 ELECTRICAL CRANE×3.2MT, SERVE 2 HOLDS, OUTREACH 4-12M
M/E(S)
1× 8NVD-48A2U (GERMANY/1990)
M/E POWER (KW)
852
A/E(S)
2×500KW, 1×200KW
GENERATOR(S)
EMERGENCY GENERATOR: 1×50KW
SHAFT GENERATOR(S)
-
PROPELLER(S)
-
COOLING SYSTEM (COMPRESSOR)
R22
SPEED/CONSUMPTIONS
ABT. 10KTS (WHILE ME LOADED 80%~85% AND SEA STATE BELOW 3 FORCE) ON 4MT MGO
FUEL TYPE
IFO
BUNKER CAPACITY (CBM)
-
TANKS CAPACITY (CBM)
MDO: 288; FW:99.7; BALLAST WATER: 39
NUMBER OF CARGO HOLDS
2
HATCH NUMBER
2
HATCH TYPE
-
HATCH SIZE (M)
2.2×3.4
HEIGHT OF HATCH COAMING (M)
-
COMPARTMENT(S)
5
DECK(S)
2
DECK HEIGHT (M)
-
CARGO CAPACITY (CBFT)
63551.4（+4654.5）
CARGO CAPACITY (CBM)
1799.58（+131.8）
FLOOR SPACE CAPACITY (SQM)
794.41
GRATING/DECK STRENGTH
-
TEMPERATURE ZONE(S)
-
TEMPERATURE (℃)
-28/+5
TYPE OF VENT SYSTEM
VENTILATION&A/C AVAILABLE IN ALL LIVE COMPARTMENTS IN ACCOMMODATION
VENT (TIMES/HOUR)
53
AIR CHANGE (TIMES/HOUR)
-
PALLET(S)
-
CONTAINER CAPACITY
8 TEU
REEFER PLUG(S)
-
SIDE DOOR(S)
-
FENDER(S)
-
ANCHOR CHAIN(S)
-
USDA CERTIFICATE
-
INSURANCE
-
CREW
20
ACCOMMODATION
FOR 40 PERSONS
INSPECTION
-
DELIVERY
-
PRICE
BUYERS OFFER
REMARK(S)
BOW THRUSTER: 1×135KW/184HP
