VESSEL NAME
REF624
TYPE
REEFER CARRIER
DEEP FREEZING OR NOT
NO
FLAG
BAHAMAS
PORT OF REGISTRY
NASSAU
BUILT YEAR
1991
BUILT PLACE
BREMER VULKAN, GERMANY
CLASSIFICATION
RINA
CLASS NOTATION
C❀ Ice Class IC❀ REF-CARGO
SS
2028-10
DD
2023-10
LOA (M)
156.89
LBP (M)
147.7
BEAM (M)
23
DEPTH (M)
13.2
SUMMER DRAFT (M)
9.5
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
10842
PANAMA GT (MT)
11981
SUEZ GT (MT)
11599.75
NT (MT)
6381
PANAMA NT (MT)
9644
SUEZ NT (MT)
8286.56
SUMMER DWT (MT)
12350
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
LDT (MT)
6516
DISPLACEMENT (MT)
19458
GEAR(S)
CRANES, 4 x 18MT / 2 x 35.4MT TWIN
M/E(S)
B&W 7L60MC 15103 BHP 100RPM
M/E POWER (KW)
11220
A/E(S)
MAN B&W 7L28/32A x 2 ， MAN B&W 5L28/32A x 1
GENERATOR(S)
DIDBN 130L/10 ， DIDBN 130g/10
SHAFT GENERATOR(S)
-
PROPELLER(S)
5850 mm
COOLING SYSTEM (COMPRESSOR)
SAB 163 HM x 3 ， SMC 108L x 2
SPEED/CONSUMPTIONS
21 KONTS, ON 40MT/DAY
FUEL TYPE
IFO
BUNKER CAPACITY (CBM)
1755
TANKS CAPACITY (CBM)
-
NUMBER OF CARGO HOLDS
4
HATCH NUMBER
4
HATCH TYPE
FOLD
HATCH SIZE (M)
12.5 × 7.6 （2,3,4）， 9.3 × 7.6 （1）
HEIGHT OF HATCH COAMING (M)
-
COMPARTMENT(S)
16
DECK(S)
4
DECK HEIGHT (M)
2.2
CARGO CAPACITY (CBFT)
590654
CARGO CAPACITY (CBM)
16732
FLOOR SPACE CAPACITY (SQM)
6687
GRATING/DECK STRENGTH
SUITABLE FOR PNEUMATIC FORKLIFTS WITH ALL-UP WEIGHT OF 6MT
TEMPERATURE ZONE(S)
8
1AB/CD, 2AB/CD, 3AB/CD, 4AB/CD
TEMPERATURE (℃)
-30/+15
TYPE OF VENT SYSTEM
FAN
VENT (TIMES/HOUR)
90
AIR CHANGE (TIMES/HOUR)
2
PALLET(S)
5060
CONTAINER CAPACITY
102FEU
REEFER PLUG(S)
78
SIDE DOOR(S)
2.05M x 2 M
FENDER(S)
-
ANCHOR CHAIN(S)
275 M
USDA CERTIFICATE
-
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
BUYERS OFFER
REMARK(S)
-
