VESSEL NAME

REF721

TYPE

REEFER CARRIER

DEEP FREEZING OR NOT

NO

FLAG

RUSSIA

PORT OF REGISTRY

NAKHODKA

BUILT YEAR

1987

BUILT PLACE

MATHIAS THESEN, GERMANY

CLASSIFICATION

RMRS

CLASS NOTATION

KM*L1 REF

SS

2021/06

DD

2019/06

LOA (M)

152.94

LBP (M)

142

BEAM (M)

22.2

DEPTH (M)

13.6

SUMMER DRAFT (M)

9

WINTER DRAFT (M)

-

TROPICAL DRAFT (M)

-

GT (MT)

12410

PANAMA GT (MT)

42429.89

SUEZ GT (MT)

37391.45

NT (MT)

4837

PANAMA NT (MT)

10443

SUEZ NT (MT)

27075.87

SUMMER DWT (MT)

11865

WINTER DWT (MT)

-

TROPICAL DWT (MT)

-

LDT (MT)

7242

DISPLACEMENT (MT)

-

GEAR(S)

DERRICKS, 8 x 5MT, OUTREACH 10M

M/E(S)

MAN K5SZ70/125 BL, 10330HP

M/E POWER (KW)

7709

A/E(S)

4 x SKL MOTOR GMBH, 6NVD-2-48A-3DF, 1000 HP x 428 RPM

GENERATOR(S)

4 x 600KW

SHAFT GENERATOR(S)

-

PROPELLER(S)

-

COOLING SYSTEM (COMPRESSOR)

5 x KULAUTOMAT S3-900

SPEED/CONSUMPTIONS

BAL: ECO(95/100RPM) ABT 11-12 KTS ON ABT 21 MT LOADED: ECO(95/100RPM) ABT 10-11 KTS ON ABT 22 MT AE: AT SEA REEFER PLANT ON/OFF: BLEND ABT 3.4MT IFO180+ ABT 1.8MT MDO // ABT 2.7MT IFO180+ ABT 1.5MT MDO IN PORT REEFER PLANT ON/OFF: BLEND ABT 3.6MT IFO180+ ABT 2.0MT MDO // ABT 2.3MT IFO180+ ABT 1.2MT MDO IN PORT BOILER WINTER/SUMMER: BLEND ABT 2.4MT IFO180+ ABT 1.2MT MDO // ABT 0.6MT IFO180+ ABT 0.3MT MDO

FUEL TYPE

IFO180

BUNKER CAPACITY (CBM)

4429

TANKS CAPACITY (CBM)

FW: 357 MGO: 335 LO: 232

NUMBER OF CARGO HOLDS

4

HATCH NUMBER

4

HATCH TYPE

-

HATCH SIZE (M)

4.0 x 6.0

HEIGHT OF HATCH COAMING (M)

-

COMPARTMENT(S)

12

DECK(S)

3

DECK HEIGHT (M)

-

CARGO CAPACITY (CBFT)

469901

CARGO CAPACITY (CBM)

13311.64

FLOOR SPACE CAPACITY (SQM)

3880

GRATING/DECK STRENGTH

-

TEMPERATURE ZONE(S)

8 1A/BC, 2A/BC, 3A/BC, 4A/BC

TEMPERATURE (℃)

-30

TYPE OF VENT SYSTEM

VERTICAL

VENT (TIMES/HOUR)

90

AIR CHANGE (TIMES/HOUR)

-

PALLET(S)

-

CONTAINER CAPACITY

-

REEFER PLUG(S)

-

SIDE DOOR(S)

-

FENDER(S)

-

ANCHOR CHAIN(S)

-

USDA CERTIFICATE

-

INSURANCE

-

CREW

-

ACCOMMODATION

-

INSPECTION

-

DELIVERY

-

PRICE

BUYERS OFFER

REMARK(S)

-
