VESSEL NAME
REF960
TYPE
REEFER CARRIER
DEEP FREEZING OR NOT
NO
FLAG
CHINA
PORT OF REGISTRY
FUZHOU
BUILT YEAR
2024
BUILT PLACE
CHINA
CLASSIFICATION
CCS
CLASS NOTATION
★CSA Refrigerated Cargo Ship
CRS(No.1,No.2,No.3,No.4 hold-20℃,30℃ Max. Sea Water);PSPC(B);Ice Class B;
★CSM G-EP;G-ECO(CD39,BWM(T));BRC;
SS
2029-09
DD
2027-09
LOA (M)
133.3
LBP (M)
127
BEAM (M)
20
DEPTH (M)
11.5
SUMMER DRAFT (M)
7.8
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
8239
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
3008
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
10406
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
LDT (MT)
-
DISPLACEMENT (MT)
-
GEAR(S)
DERRICK 8 x 2.5 MT
M/E(S)
Ningbo C.S.I. Power & Machinery, NL8340ZC4, 4800KW, 650 RPM
M/E POWER (KW)
4800
A/E(S)
-
GENERATOR(S)
4 x SB-HW4-500-6P, 500KW AT 1000RPM 1 x SB-HW4.D-200, 200KW AT 1500RPM
SHAFT GENERATOR(S)
KANGFU TECHNOLOGY SB-HW4B-450, 500KW, 1000RPM, 50HZ
PROPELLER(S)
-
COOLING SYSTEM (COMPRESSOR)
3 SETS, CJJZLG16FW, R507A
SPEED/CONSUMPTIONS
14.50 KNOTS
FUEL TYPE
BUNKER CAPACITY (CBM)
-
TANKS CAPACITY (CBM)
-
NUMBER OF CARGO HOLDS
4
HATCH NUMBER
4
HATCH TYPE
-
HATCH SIZE (M)
8.10 x 6.30
HEIGHT OF HATCH COAMING (M)
-
COMPARTMENT(S)
-
DECK(S)
1
DECK HEIGHT (M)
-
CARGO CAPACITY (CBFT)
442556
CARGO CAPACITY (CBM)
12537
FLOOR SPACE CAPACITY (SQM)
GRATING/DECK STRENGTH
-
TEMPERATURE ZONE(S)
TEMPERATURE (℃)
-20/30
TYPE OF VENT SYSTEM
-
VENT (TIMES/HOUR)
-
AIR CHANGE (TIMES/HOUR)
-
PALLET(S)
-
CONTAINER CAPACITY
REEFER PLUG(S)
-
SIDE DOOR(S)
-
FENDER(S)
-
ANCHOR CHAIN(S)
-
USDA CERTIFICATE
-
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
DELIVERY
PRICE
USD 15.0 M
REMARK(S)
