VESSEL NAME
REF927
TYPE
REEFER CARRIER
DEEP FREEZING OR NOT
NO
FLAG
CHINA
PORT OF REGISTRY
ZHOUSHAN
BUILT YEAR
2022
BUILT PLACE
CHINA
CLASSIFICATION
CCS
CLASS NOTATION
★CSA★CSM; CRS(NO.1、NO.2、NO.4 Hold -35℃, 35℃ Max.Sea Water,NO.3 -50℃, 35℃ Max.Sea Water);Ice Class B;PSPC(B)
SS
2027-03-13
DD
-
LOA (M)
123.43
LBP (M)
113.6
BEAM (M)
18
DEPTH (M)
10.2
SUMMER DRAFT (M)
7.25
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
6244
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
3050
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
7464
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
LDT (MT)
-
DISPLACEMENT (MT)
3961.046
GEAR(S)
DERRICKS, 4 x 5MT
M/E(S)
HANSHIN LH46LA, 4500BHP 220RPM
M/E POWER (KW)
3309
A/E(S)
2 x MAN 6L23/30H, 810KW 720RPM
GENERATOR(S)
1FC6 406-6SA42*350.00*400*2; HFC6 506-84K*700.00*400*2
SHAFT GENERATOR(S)
-
PROPELLER(S)
-
COOLING SYSTEM (COMPRESSOR)
3 x MOON TECH ZCLG20S16MSY
COOLED TUBE TYPE
SPEED/CONSUMPTIONS
12.5 KTS
FUEL TYPE
-
BUNKER CAPACITY (CBM)
611.74
TANKS CAPACITY (CBM)
MDO: 274.40
FW: 659.44
NUMBER OF CARGO HOLDS
4
HATCH NUMBER
4
HATCH TYPE
-
HATCH SIZE (M)
4*5.50×5.50
HEIGHT OF HATCH COAMING (M)
-
COMPARTMENT(S)
8
DECK(S)
2
DECK HEIGHT (M)
-
CARGO CAPACITY (CBFT)
359057
CARGO CAPACITY (CBM)
10171.59
FLOOR SPACE CAPACITY (SQM)
-
GRATING/DECK STRENGTH
-
TEMPERATURE ZONE(S)
-
TEMPERATURE (℃)
-35 (NO.3 CH -55)
TYPE OF VENT SYSTEM
-
VENT (TIMES/HOUR)
-
AIR CHANGE (TIMES/HOUR)
-
PALLET(S)
-
CONTAINER CAPACITY
-
REEFER PLUG(S)
-
SIDE DOOR(S)
-
FENDER(S)
-
ANCHOR CHAIN(S)
-
USDA CERTIFICATE
-
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
CHINA
DELIVERY
CHINA
PRICE
USD 18.5 MILLION
REMARK(S)
-
