VESSEL NAME
REF924
TYPE
REEFER CARRIER
DEEP FREEZING OR NOT
NO
FLAG
CHINA
PORT OF REGISTRY
NINGBO
BUILT YEAR
2016
BUILT PLACE
CHINA
CLASSIFICATION
CCS
CLASS NOTATION
-
SS
2026.04.25
DD
-
LOA (M)
120.8
LBP (M)
110.8
BEAM (M)
18
DEPTH (M)
10.2
SUMMER DRAFT (M)
7
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
5784
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
2645
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
6862
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
LDT (MT)
-
DISPLACEMENT (MT)
10710.3
GEAR(S)
DERRICKS, 4 x 5MT
M/E(S)
HANSHIN LH46LA, 4435HP/3309KW 220RPM
M/E POWER (KW)
3309
A/E(S)
WEICHAI DIESEL, 3 x 6210ZL, 6CYL, 500KW 750RPM
WEICHAI DIESEL, 1 x ZL170-D2, 6CYL, 300KW 1000RPM
EMERGENCY: WEICHAI DIESEL, 1 x WP6CD132-15, 132KW 1500RPM
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
-
COOLING SYSTEM (COMPRESSOR)
COILED
COMPRESSORS, 4 x 132KW, MADE YANTAI, CHINA
SPEED/CONSUMPTIONS
13.5 KTS
FUEL TYPE
-
BUNKER CAPACITY (CBM)
548.28
TANKS CAPACITY (CBM)
MDO: 300
NUMBER OF CARGO HOLDS
4
HATCH NUMBER
-
HATCH TYPE
-
HATCH SIZE (M)
-
HEIGHT OF HATCH COAMING (M)
-
COMPARTMENT(S)
12
DECK(S)
3
DECK HEIGHT (M)
-
CARGO CAPACITY (CBFT)
305280.4
CARGO CAPACITY (CBM)
8648.17
FLOOR SPACE CAPACITY (SQM)
-
GRATING/DECK STRENGTH
-
TEMPERATURE ZONE(S)
-
TEMPERATURE (℃)
-25/+35
TYPE OF VENT SYSTEM
-
VENT (TIMES/HOUR)
-
AIR CHANGE (TIMES/HOUR)
-
PALLET(S)
-
CONTAINER CAPACITY
-
REEFER PLUG(S)
-
SIDE DOOR(S)
-
FENDER(S)
-
ANCHOR CHAIN(S)
-
USDA CERTIFICATE
-
INSURANCE
-
CREW
34
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
BUYERS OFFER
REMARK(S)
-
