VESSEL NAME
TNK009
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
PANAMA
PORT OF REGISTRY
MONROVIA
BUILT YEAR
1992
BUILT PLACE
ASAKAWA SHIP BUILDER CO, JAPAN
CLASSIFICATION
NK
CLASS NOTATION
TANKER MOLASSES OR OILS - FLASHPOINT BELOW 60C AND CHEMICALS TYPES II AND II ESP MNS
SS
-
DD
-
LOA (M)
111.56
LBP (M)
104.30
BEAM (M)
18.80
DEPTH (M)
9.56
SUMMER DRAFT (M)
7.61
WINTER DRAFT (M)
7.46
TROPICAL DRAFT (M)
7.77
GT (MT)
4989.00
PANAMA GT (MT)
-
SUEZ GT (MT)
5361.99
NT (MT)
2747.00
PANAMA NT (MT)
5403.00
SUEZ NT (MT)
4712.00
SUMMER DWT (MT)
9103.00
WINTER DWT (MT)
8828.00
TROPICAL DWT (MT)
9378.00
DISPLACEMENT (MT)
11865.00
LDT (MT)
-
GEAR(S)
CRANE, 1 x 5MT
M/E(S)
MITSUBISHI 7UEC37LA 4400BHP
M/E POWER (KW)
3283
A/E(S)
-
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
IFO180
BUNKER CAPACITY (CBM)
519.3
TANKS CAPACITY (CBM)
SLOP TANK：582, MGO: 75.74
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
18
CARGO CAPACITY98% (CBFT)
338644
CARGO CAPACITY98% (CBM)
9593.3
COATING/MATERIAL OF HOLD(S)
STAINLESS STEEL
HEATING SYSTEM
STAINLESS STEEL HEATING COILS
SACRIFICIAL ANODE
ZONC
IGS
-
PUMP(S)
CENTRIFUGAI:
1 x 250 CBM/HR
9 x 200 CBM/HR
8 x 150 CBM/HR
2 x 10 0CBM/HR
1 x 70 CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
YES
SIDE THRUSTER(S)
BOW THRUSTER: 1 x 350BHP, 260.99KW
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
BUYERS OFFER
REMARK(S)
SBT: 2491.25CBM
BALLAST TANK ARE EPOXY COATED
