VESSEL NAME
TNK041
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
-
FLAG
RUSSIA
PORT OF REGISTRY
VLADIVOSTOK
BUILT YEAR
1985
BUILT PLACE
RUSE, BULGARIA
CLASSIFICATION
RMRS
CLASS NOTATION
KM*R1 ICE 3 OIL RECOVERY SHIP, R1 LIMITED NAVIGATION AREA（400MILES）
SS
-
DD
-
LOA (M)
77.53
LBP (M)
73.24
BEAM (M)
14.00
DEPTH (M)
6.50
SUMMER DRAFT (M)
5.35
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
1914.00
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
1015.00
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
3317.00
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
DISPLACEMENT (MT)
4400.00
LDT (MT)
-
GEAR(S)
-
M/E(S)
NVD 48 A -2U
M/E POWER (KW)
-
A/E(S)
2 x 180KW, 400V, 1500RPM, 50HZ
GENERATOR(S)
STAND BY GENERATOR：1 x 50KW, 400V,1500RPM, 50HZ
SHAFT GENERATOR(S)
-
PROPELLER(S)
STEERABLE DUCTED PROPELLER
SPEED /CONSUMPTIONS
MAX：11KTS，5.5MT/DAY
ECO：8KTS，4.5MT/DAY
IN PORT：1.5-1.8MT/DAY
STANDBY：1.8-2.3MT/DAY
FUEL TYPE
MGO
BUNKER CAPACITY (CBM)
AT LEAST 110MT （FOR MIN 20 DAYS ON MAX SPEED）
TANKS CAPACITY (CBM)
MGO/MDO: 120，P WATER：14MT，D WATER：140MT，LIQUID MUD：51MT
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
-
CARGO CAPACITY98% (CBFT)
120867.2
CARGO CAPACITY98% (CBM)
3424
COATING/MATERIAL OF HOLD(S)
-
HEATING SYSTEM
-
SACRIFICIAL ANODE
-
IGS
-
PUMP(S)
2 x 90CBM / HR
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
BOW THRUSTER: 1 x 100KW
INSURANCE
-
CREW
-
ACCOMMODATION
3 x 1 BERTH，4 x 2BERTH，1 x 4BERTH
INSPECTION
-
DELIVERY
-
PRICE
AT LEAST USD 1.3 MILLION
REMARK(S)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
