VESSEL NAME
TNK055
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
SINGAPORE
PORT OF REGISTRY
SINGAPORE
BUILT YEAR
1998
BUILT PLACE
HAE DONG SHIPBUILDING, KOREA
CLASSIFICATION
LR
CLASS NOTATION
100A1,DOUBLE HULL, OIL&CHEMICAL TANKER TYPE2, SG1.5,ESP, LI, LMC
SS
-
DD
-
LOA (M)
99.90
LBP (M)
93.00
BEAM (M)
15.72
DEPTH (M)
7.80
SUMMER DRAFT (M)
6.28
WINTER DRAFT (M)
6.17
TROPICAL DRAFT (M)
6.41
GT (MT)
3166.00
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
1531.00
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
4742.00
WINTER DWT (MT)
4835.00
TROPICAL DWT (MT)
5166.00
DISPLACEMENT (MT)
6795.00
LDT (MT)
-
GEAR(S)
1 x 0.9MT HOSE CRANE, OUTREACH: 2 M
M/E(S)
-
M/E POWER (KW)
-
A/E(S)
-
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
IFO180
BUNKER CAPACITY (CBM)
226.5
TANKS CAPACITY (CBM)
MGO: 68.35, SLOP TANK:179
COMPARTMENT(S)
10
NUMBER OF CARGO HOLDS
5
CARGO CAPACITY98% (CBFT)
186419.3
CARGO CAPACITY98% (CBM)
5281
COATING/MATERIAL OF HOLD(S)
EPOXY
HEATING SYSTEM
STAINLESS STEEL STEAM HEATING COILS
SACRIFICIAL ANODE
-
IGS
-
PUMP(S)
10 x 160 CBM / HR
2 x 100 CBM / HR
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
-
INSURANCE
POLLUTION LIABILITY: USD 1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
USD 4.8 MILLION
REMARK(S)
-
