VESSEL NAME
TNK079
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
PANAMA
PORT OF REGISTRY
-
BUILT YEAR
1995
BUILT PLACE
FOKUOKA SHIP BUILDING CO.,LTD, JAPAN
CLASSIFICATION
KR
CLASS NOTATION
OIL TANKER (DOUBLE HULL) ESP(FAC), PRODUCT ERS ENV (IAFS, IOPP, ISPP, IAPP) LI, IMO II
SS
-
DD
-
LOA (M)
110.00
LBP (M)
102.32
BEAM (M)
16.06
DEPTH (M)
9.30
SUMMER DRAFT (M)
6.76
WINTER DRAFT (M)
5.59
TROPICAL DRAFT (M)
5.83
GT (MT)
4228.00
PANAMA GT (MT)
-
SUEZ GT (MT)
4541.27
NT (MT)
1926.00
PANAMA NT (MT)
4228.00
SUEZ NT (MT)
4228.00
SUMMER DWT (MT)
6502.00
WINTER DWT (MT)
4833.38
TROPICAL DWT (MT)
5164.98
DISPLACEMENT (MT)
8685.00
LDT (MT)
-
GEAR(S)
CRANES: 1 x 3 MT, CENTER
M/E(S)
1 B&W 6S26MC 3,270 BHP 250 RPM
M/E POWER (KW)
2440
A/E(S)
-
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
PIXED PITCH
SPEED /CONSUMPTIONS
AVERAGE: 11KTS, 9KL(IFO180) / DAY + 0.85KL(MDO) / DAY
FUEL TYPE
IFO180
BUNKER CAPACITY (CBM)
357.88
TANKS CAPACITY (CBM)
MDO:42.28
COMPARTMENT(S)
5
NUMBER OF CARGO HOLDS
12
CARGO CAPACITY98% (CBFT)
243187.7
CARGO CAPACITY98% (CBM)
6889.17
COATING/MATERIAL OF HOLD(S)
EPOXY
HEATING SYSTEM
STAINLESS HEATING COILS STEAM HEATING
SACRIFICIAL ANODE
ZINC
IGS
-
PUMP(S)
CARGO (SCREW): 2 x 500CBM / HR
STRIPPING (SCREW): 1 x 100 CBM / HR
BALLAST(CENTRIFUGAL): 2 x 300CBM / HR
ONE PUMP FOR SINGLE HOLD OR NOT
NOT
SIDE THRUSTER(S)
-
INSURANCE
1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
USD 5.2 MILLION
REMARK(S)
DIAPLACEMENT (MT): 7016.54(WINTER), 7348.14(TROPICAL)
SBT: 2636.93CBM
BALLAST TANKS ARE ZINC COATED
SLOP TANKS ARE EPOXY COATED
