VESSEL NAME
TNK105
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
SINGAPORE
PORT OF REGISTRY
SINGAPORE
BUILT YEAR
2006
BUILT PLACE
ZHEJIANG SOPO SHIPBUILDING， CHINA
CLASSIFICATION
ABS
CLASS NOTATION
A1(E) FUEL OIL CARRIERS, COASTAL SEVISE *AMS
SS
-
DD
-
LOA (M)
99.80
LBP (M)
94.00
BEAM (M)
18.00
DEPTH (M)
10.00
SUMMER DRAFT (M)
7.00
WINTER DRAFT (M)
6.85
TROPICAL DRAFT (M)
7.15
GT (MT)
4969.00
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
1859.00
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
6956.00
WINTER DWT (MT)
6802.00
TROPICAL DWT (MT)
7263.00
DISPLACEMENT (MT)
9748.00
LDT (MT)
-
GEAR(S)
CRANE: 1 x 0.9MT, OUTREACH 5M
M/E(S)
-
M/E POWER (KW)
-
A/E(S)
-
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
MDO/MGO
BUNKER CAPACITY (CBM)
-
TANKS CAPACITY (CBM)
MDO/MGO: 291.5，SLOP TANK：282.55
COMPARTMENT(S)
5
NUMBER OF CARGO HOLDS
10
CARGO CAPACITY98% (CBFT)
252806.25
CARGO CAPACITY98% (CBM)
7161.65
COATING/MATERIAL OF HOLD(S)
EPOXY (ONLY FOR DECK HEAD)
HEATING SYSTEM
-
SACRIFICIAL ANODE
YES
IGS
-
PUMP(S)
CARGO PUMPS(SCREW): 2 x 750CBM/HR
STRIPPING PUMP(GEAR):1 x 300CBM/HR
BALLAST PUMP(CENTRIFUGAL):2 x 300CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
BOW THRUSTER: 1 x 300KW
INSURANCE
POLLUTION LIABILITY COVERAGE: USD 1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
BUYERS OFFER
REMARK(S)
DISPLACEMENT(MT): 9518(WINTER), 9979(TROPICAL)
SBT: 2928.68CBM
BALLAST TANK AND SLOP TANK ARE COATED
