VESSEL NAME
TNK108
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL / DOUBLE BOTTOM / DOUBLE SIDES
FLAG
RUSSIA
PORT OF REGISTRY
NAKHODKA
BUILT YEAR
1995
BUILT PLACE
SHIPBUILDING COMPANY, LTD, MALTA
CLASSIFICATION
RMRS
CLASS NOTATION
DNV 1A1 TANKER FOR OIL PRODUCTS ESP, TANKER FOR CHEMICALS, F-AMC, PP3. ICE - 1A, E0， W1-OC, TMON, BIS 1990
REG NOT: SHIPTYPE 2, A2，B3，C3，V3，F2，K,S TR,0.1，D=1540KG/M3
SS
-
DD
-
LOA (M)
115.10
LBP (M)
108.00
BEAM (M)
18.50
DEPTH (M)
9.88
SUMMER DRAFT (M)
7.50
WINTER DRAFT (M)
7.35
TROPICAL DRAFT (M)
7.66
GT (MT)
5378.00
PANAMA GT (MT)
-
SUEZ GT (MT)
4571.00
NT (MT)
2714.00
PANAMA NT (MT)
5378.00
SUEZ NT (MT)
-
SUMMER DWT (MT)
8530.00
WINTER DWT (MT)
8215.00
TROPICAL DWT (MT)
8710.00
DISPLACEMENT (MT)
11428.00
LDT (MT)
-
GEAR(S)
CRANES，2 x 2MT，HOSE CRANE LOCTAED AT MIDSHIP，PROVISION CRANE LOCATED AT AFT PORT SIDE
M/E(S)
NORMO BRM-8
M/E POWER (KW)
3530
A/E(S)
-
GENERATOR(S)
3 x 350KW，1800RPM
SHAFT GENERATOR(S)
1100KW
PROPELLER(S)
CPP
SPEED /CONSUMPTIONS
MAX SPEED：14.5KTS，14MT IFO + 0.5MT MGO
IN PORT ：1.8MT MGO
FUEL TYPE
IFO380
BUNKER CAPACITY (CBM)
370
TANKS CAPACITY (CBM)
MGO:125，SLOP TANK：158
COMPARTMENT(S)
10
NUMBER OF CARGO HOLDS
10
CARGO CAPACITY98% (CBFT)
340645
CARGO CAPACITY98% (CBM)
9650
COATING/MATERIAL OF HOLD(S)
EPOXY
HEATING SYSTEM
HEAT EXCHANGER
SACRIFICIAL ANODE
-
IGS
-
PUMP(S)
CARGO PUMP (SUBMERGED PUMP): 10 x 290CBM/HR, 2 x 100CBM/HR
BALLAST PUMP: 2 x 350CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
YES
SIDE THRUSTER(S)
BOW THRUSTER: 440KW
INSURANCE
POLLUTION LIABILITY COVERAGE: USD 1 BILLION
CREW
-
ACCOMMODATION
14 SINGLE BERTH CABINS
INSPECTION
KOREA
DELIVERY
KOREA
PRICE
USD 3.2 MILLION
REMARK(S)
DISPLACEMENT (MT): 11162(WINTER), 11700(TROPICAL)
SBT: 3796CBM
BALLAST TANK AND SLOP TANK ARE COATED
BWTS FITTED
SINGAPORE BASED OWNER
