VESSEL NAME
TNK133
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
MALAYSIA
PORT OF REGISTRY
PORT KELANG
BUILT YEAR
2011
BUILT PLACE
BOUSTEAD PENANG SHIPYARD SDN, BHD, MALAYSIA
CLASSIFICATION
BV
CLASS NOTATION
1*HULL*MACH OIL/CHEMICAL TANKER ESP, OIL TANKER ESP, UNRESTRICTED NAVIGATION
SS
-
DD
-
LOA (M)
104.90
LBP (M)
98.50
BEAM (M)
19.05
DEPTH (M)
9.90
SUMMER DRAFT (M)
6.70
WINTER DRAFT (M)
6.55
TROPICAL DRAFT (M)
6.83
GT (MT)
5532.00
PANAMA GT (MT)
-
SUEZ GT (MT)
5764.26
NT (MT)
1996.00
PANAMA NT (MT)
-
SUEZ NT (MT)
4240.00
SUMMER DWT (MT)
7299.00
WINTER DWT (MT)
7129.00
TROPICAL DWT (MT)
7469.00
DISPLACEMENT (MT)
10147.00
LDT (MT)
2848.00
GEAR(S)
CRANE：1 x 3吨
M/E(S)
DAIHATSU 6DKM-36 600RPM 3942BHP
M/E POWER (KW)
2942
A/E(S)
-
GENERATOR(S)
3 x 400KW
1 x 75KW
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
IFO
BUNKER CAPACITY (CBM)
420.35
TANKS CAPACITY (CBM)
MGO/MDO: 111.96, SLOP TANK：264.74
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
12
CARGO CAPACITY98% (CBFT)
295976.38
CARGO CAPACITY98% (CBM)
8384.6
COATING/MATERIAL OF HOLD(S)
MARIINELINE
HEATING SYSTEM
STAINLESS STEEL HEATING COILS
SACRIFICIAL ANODE
-
IGS
-
PUMP(S)
CARGO PUMP（CENTRIFUGAL）：10 x 200 CBM/HR，2 x 125CBM/HR
BALLAST PUMP（CENTRIFUGAL）：2 x 200 CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
YES
SIDE THRUSTER(S)
-
INSURANCE
POLLUTION LIABILITY COVERAGE: USD 1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
FAR EAST
DELIVERY
FAR EAST
PRICE
USD 8 MILLION
REMARK(S)
DISPLACEMENT (MT): 9878 (WINTER), 10372 (TROPICAL)
SBT: 3750.3 CBM
BALLAST TANK ARE EPOXY COATED
