VESSEL NAME
TNK134
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
MALAYSIA
PORT OF REGISTRY
PORT KLANG
BUILT YEAR
2011
BUILT PLACE
BOUSTEAD PENANG SHIPYARD SDN, MALAYSIA
CLASSIFICATION
BV
CLASS NOTATION
1 HULL + MACH OIL / CHEMICAL TANKER ESP, OIL TANKER ESP, UNRESTRICTED NAVIGATION
SS
-
DD
-
LOA (M)
104.90
LBP (M)
98.50
BEAM (M)
19.00
DEPTH (M)
9.90
SUMMER DRAFT (M)
6.70
WINTER DRAFT (M)
6.55
TROPICAL DRAFT (M)
6.83
GT (MT)
5532.00
PANAMA GT (MT)
-
SUEZ GT (MT)
5764.26
NT (MT)
1996.00
PANAMA NT (MT)
-
SUEZ NT (MT)
4240.00
SUMMER DWT (MT)
7299.00
WINTER DWT (MT)
7129.00
TROPICAL DWT (MT)
7469.00
DISPLACEMENT (MT)
10147.00
LDT (MT)
2848.00
GEAR(S)
CRANE, 3 x 3 MT CENTRAL, 1 x 1.5MT PORT SIDE, 1 x 1 MT STABOARD SIDE
M/E(S)
DAIHATSU 6DKM-36 600RPM 4499BHP
M/E POWER (KW)
2942
A/E(S)
-
GENERATOR(S)
3 x 350KW, 1 x 75KW
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
HFO
BUNKER CAPACITY (CBM)
406.2
TANKS CAPACITY (CBM)
MGO:109.6，SLOP TANKS：263.69
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
12
CARGO CAPACITY98% (CBFT)
295976.38
CARGO CAPACITY98% (CBM)
8384.6
COATING/MATERIAL OF HOLD(S)
MARINE LINE
HEATING SYSTEM
STAINLESS STEEL HEATING COILS
SACRIFICIAL ANODE
-
IGS
-
PUMP(S)
CARGO PUMP: 10 x 200CBM/HR, 2 x 125CBM/HR
BALLAST PUMP: 2 x 200CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
YES
SIDE THRUSTER(S)
-
INSURANCE
POLLUTION LIABILITY COVERAGE: USD 1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
FAREAST
DELIVERY
FAREAST
PRICE
USD 8 MILLION
REMARK(S)
DISPLACEMENT(MT): 9878(WINTER), 10372(TROPICAL)
SBT:3750.8CBM
BALLAST TANKS AND SLOPE TANKS ARE COATED
