新西兰泛洋船务有限公司 泛洋船务有限公司（中国） VANOCEAN SHIPPING CO., LTD. Room 2213, The Spaces International Center, No.8 Dong Da Qiao Road, Chaoyang District, Beijing, China 100020 北京朝阳朝外大街东大桥路8号尚都国际中心2213室（100020） REEFER OWNERS & OPERATOR –BROKER –CHARTERING--S&P--OCEAN BUNKERING TEL: +86-10-51650592, +86-10-58700592 FAX: +86-10-58700591 MB: +86-13901108086, +86-13911066056 E-MAIL: vosco@vanocean.com reefer@vanocean.com VESSEL PARTICULARS

-

VESSEL NAME

TNK137

TYPE

OIL/CHEMICAL TANKER

HULL TYPE

-

FLAG

KOREA

PORT OF REGISTRY

JEJU CHEJU

BUILT YEAR

2000

BUILT PLACE

FULUOKA SHIPBUILDING, JAPAN

CLASSIFICATION

NK

CLASS NOTATION

NS*(TANKER OILS - FLASH POINT BELOW 60℃ AND CHEMICALS TYPE II AND III) MNS*

SS

-

DD

-

LOA (M)

110.00

LBP (M)

103.00

BEAM (M)

18.53

DEPTH (M)

9.60

SUMMER DRAFT (M)

7.21

WINTER DRAFT (M)

7.06

TROPICAL DRAFT (M)

7.36

GT (MT)

5160.00

PANAMA GT (MT)

-

SUEZ GT (MT)

5160.00

NT (MT)

2420.00

PANAMA NT (MT)

4395.00

SUEZ NT (MT)

2420.00

SUMMER DWT (MT)

7849.25

WINTER DWT (MT)

7597.41

TROPICAL DWT (MT)

8102.54

DISPLACEMENT (MT)

10499.15

LDT (MT)

-

GEAR(S)

CRANE 1 x 5 MT

M/E(S)

2 SA 6 CY 5281BHP

M/E POWER (KW)

3883

A/E(S)

-

GENERATOR(S)

1625KW

SHAFT GENERATOR(S)

-

PROPELLER(S)

FPP

SPEED /CONSUMPTIONS

14.8KTS

FUEL TYPE

CFO

BUNKER CAPACITY (CBM)

567.91

TANKS CAPACITY (CBM)

MGO/MDO: 99.92， SLOP TANK：289.48

COMPARTMENT(S)

10

NUMBER OF CARGO HOLDS

12

CARGO CAPACITY98% (CBFT)

287089.25

CARGO CAPACITY98% (CBM)

8132.84

COATING/MATERIAL OF HOLD(S)

STAINLESS STEEL

HEATING SYSTEM

STAINLESS STEEL HEATING COIL

SACRIFICIAL ANODE

ZINC

IGS

-

PUMP(S)

CARGO (SUBMERGED): 10 x 330CBM/HR, 3 x 100CBM/HR BALLAST(CENTRIFUGAL): 2 x 300 CBM/HR

ONE PUMP FOR SINGLE HOLD OR NOT

YES

SIDE THRUSTER(S)

-

INSURANCE

POLLUTION LIABILITY: USD 1 BILLION

CREW

-

ACCOMMODATION

-

INSPECTION

-

DELIVERY

-

PRICE

USD 7 MILLION

REMARK(S)

DISPLACEMENT(MT):10274.31(WINTER), 10752.44(TROPICAL) SBT:2806.65CBM BALLAST TANK ARE EPOXY COATED TANKER OILS - FLASH POINT BELOW 60℃

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-
