VESSEL NAME
TNK138
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL DOUBLE BOTTOM
FLAG
MALAYSIA
PORT OF REGISTRY
PORT KELANG
BUILT YEAR
2008
BUILT PLACE
NOK BONG SHIPBUILDING CO. LTD, KOREA
CLASSIFICATION
BV
CLASS NOTATION
A1, CHEMICAL CARRIER, OIL CARRIER, E, AMS,
VEC, TCM
SS
-
DD
-
LOA (M)
121.55
LBP (M)
113.4
BEAM (M)
19.2
DEPTH (M)
10.8
SUMMER DRAFT (M)
8.31
WINTER DRAFT (M)
8.14
TROPICAL DRAFT (M)
8.49
GT (MT)
7057
PANAMA GT (MT)
-
SUEZ GT (MT)
6334.32
NT (MT)
3430
PANAMA NT (MT)
5981
SUEZ NT (MT)
5883.8
SUMMER DWT (MT)
10778.22
WINTER DWT (MT)
10431.04
TROPICAL DWT (MT)
1127.394
DISPLACEMENT (MT)
14420.576
LDT (MT)
3642.36
GEAR(S)
1 x 10MT，OUTREACH：4.4M
M/E(S)
-
M/E POWER (KW)
-
A/E(S)
-
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
MFO380
BUNKER CAPACITY (CBM)
472.96
TANKS CAPACITY (CBM)
MGO: 47.93，SLOP TANK：443.7，
COMPARTMENT(S)
6
NUMBER OF CARGO HOLDS
10 CARGO HOLDS，2 SLOP HOLDS
CARGO CAPACITY98% (CBFT)
400708.66
CARGO CAPACITY98% (CBM)
11351.52
COATING/MATERIAL OF HOLD(S)
MARINE LINE COATED
HEATING SYSTEM
STAINLESS STEEL HEATING COILED
SACRIFICIAL ANODE
ZINC
IGS
-
PUMP(S)
CARGO (SUBMERGED): 10 x 300 CBM/HR，2 x 200CBM/HR
STRIPPING: 70CBM/HR
BALLAST (SINGLE STAGE, HORIZONTAL, CENTRIFUGAL): 2 x 350CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
YES
SIDE THRUSTER(S)
-
INSURANCE
POLLUTION LIABILITY COVERAGE: USD 1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
USD 12 MILLION
REMARK(S)
DISPLACEMENT (MT): 14073.39(WINTER), 14769.75(TROPICAL)
SBT: 4092.82CBM
BALLAST TANKS ARE EPOXY COATED
TRADING BETWEEN FAR EAST AND ARGENTINA
