VESSEL NAME
TNK150
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
PANAMA
PORT OF REGISTRY
PANAMA
BUILT YEAR
1999
BUILT PLACE
ASAKAWA SHIPBUILDING CO.,LTD, JAPAN
CLASSIFICATION
NK
CLASS NOTATION
NS*(TM OR OB AND C II AND III) ,MNS* (ESP) IMO II/III
SS
2019-06
DD
-
LOA (M)
118.00
LBP (M)
110.00
BEAM (M)
19.20
DEPTH (M)
10.40
SUMMER DRAFT (M)
8.26
WINTER DRAFT (M)
8.08
TROPICAL DRAFT (M)
8.43
GT (MT)
6001.00
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
3313.00
PANAMA NT (MT)
6001.00
SUEZ NT (MT)
-
SUMMER DWT (MT)
10749.00
WINTER DWT (MT)
10421.00
TROPICAL DWT (MT)
11078.00
DISPLACEMENT (MT)
13942.00
LDT (MT)
-
GEAR(S)
CRANE, 1 x 5 MT, OUTREACH 2.4M
M/E(S)
-
M/E POWER (KW)
-
A/E(S)
-
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
IFO380
BUNKER CAPACITY (CBM)
602.37
TANKS CAPACITY (CBM)
MDO:96.17，SLOP TANK：1092
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
18
CARGO CAPACITY98% (CBFT)
364331.3
CARGO CAPACITY98% (CBM)
10321
COATING/MATERIAL OF HOLD(S)
STAINLESS STEE
HEATING SYSTEM
STAINLESS STEEL STEAM HEATING MAX 90 DEG C
SACRIFICIAL ANODE
ZINC
IGS
-
PUMP(S)
CARGO: 18 x 200 CBM/HR
BALLAST (CENTRIFUGAL): 1 x 250 CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
YES
SIDE THRUSTER(S)
-
INSURANCE
POLLUTION LIABILITY COVERAGE, USD 1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
USD 8.2 MILLION
REMARK(S)
DISPLACEMENT (MT): 13614 (WINTER), 14271 (TROPICAL)
SBT: 2762.5CBM
4 PUMPS CAN BE RUN AT FULL CAPACITY SIMULTANEOUSLY
