VESSEL NAME
TNK157
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE BOTTOM, DOUBLE SIDE, DOUBLE HULL
FLAG
PANAMA
PORT OF REGISTRY
-
BUILT YEAR
2010
BUILT PLACE
RONGCHENG SHENFEI SHIPBUILDING CO LTD
CLASSIFICATION
BV
CLASS NOTATION
-
SS
-
DD
-
LOA (M)
102.70
LBP (M)
95.00
BEAM (M)
17.80
DEPTH (M)
8.80
SUMMER DRAFT (M)
6.50
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
-
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
-
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
5500.00
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
DISPLACEMENT (MT)
-
LDT (MT)
-
GEAR(S)
-
M/E(S)
HYUNDAI HIMSEN 9H25/33P MCR 3562 BHP 900RPM
M/E POWER (KW)
2658
A/E(S)
-
GENERATOR(S)
2 x 400KW 440V 60HZ
1 x 400KW 440V 60HZ
SHAFT GENERATOR(S)
-
PROPELLER(S)
-
SPEED /CONSUMPTIONS
-
FUEL TYPE
-
BUNKER CAPACITY (CBM)
-
TANKS CAPACITY (CBM)
SLOP TANK: 245
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
10
CARGO CAPACITY98% (CBFT)
238098
CARGO CAPACITY98% (CBM)
6745
COATING/MATERIAL OF HOLD(S)
EPOXY COATED
HEATING SYSTEM
STAINLESS STEEL COILED MAX 75 DEG C
SACRIFICIAL ANODE
-
IGS
-
PUMP(S)
CARGO: 2 x 750CBM/HR, 1 x 300CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
No
SIDE THRUSTER(S)
BOW THRUSTER: 1 x 408HP 300KW
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
USD 6 MILLION
REMARK(S)
SBT
GRADE: 3
