VESSEL NAME
TNK176
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
KOREA
PORT OF REGISTRY
JEJU
BUILT YEAR
1998
BUILT PLACE
HITACHI MUKAISHIMA MARINE CO.LTD, JAPAN
CLASSIFICATION
KR
SS
2018-08
DD
-
LOA (M)
112.50
LBP (M)
105.00
BEAM (M)
18.80
DEPTH (M)
9.65
SUMMER DRAFT (M)
7.75
WINTER DRAFT (M)
7.59
TROPICAL DRAFT (M)
7.75
GT (MT)
5483.00
PANAMA GT (MT)
-
SUEZ GT (MT)
4700.87
NT (MT)
2602.00
PANAMA NT (MT)
4665.00
SUEZ NT (MT)
2602.00
SUMMER DWT (MT)
8823.00
WINTER DWT (MT)
8545.60
TROPICAL DWT (MT)
8823.00
DISPLACEMENT (MT)
11790.00
LDT (MT)
-
GEAR(S)
CRANE. 1 x 3MT, MIDSHIP, OUTREACH 3M
M/E(S)
-
M/E POWER (KW)
-
A/E(S)
-
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
IFO380
BUNKER CAPACITY (CBM)
525.76
TANKS CAPACITY (CBM)
MDO/MGO: 92
COMPARTMENT(S)
16
NUMBER OF CARGO HOLDS
16
CARGO CAPACITY98% (CBFT)
320030
CARGO CAPACITY98% (CBM)
9066
COATING/MATERIAL OF HOLD(S)
STAINLESS STEEL
HEATING SYSTEM
STAINLESS STEEL HEATING COILS
SACRIFICIAL ANODE
ZINC
IGS
-
PUMP(S)
CARGO (CENTRIFUGAL): 2 x 250CBM/HR, 8 x 150CBM/HR,6 x 100CBM/HR
BALLAST (CENTRIFUGAL): 1 x 300CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
-
INSURANCE
POLLUTION LIABILITY COVERAGE: USD 1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
USD 7 MILLION
REMARK(S)
DISPLACEMENT(MT): 11512.60 (WINTER), 11790.00 (TROPICAL)
SBT:3622CBM
BALLAST TANK ARE EPOXY COATED
SLOP TANKS ARE MADE BY STAINLESS STEEL
