VESSEL NAME
TNK187
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
UAE
PORT OF REGISTRY
DUBAI
BUILT YEAR
2004
BUILT PLACE
HIGAKI,JAPAN
CLASSIFICATION
NK
CLASS NOTATION
NS *(TOB/CT II&III) (ESP) MNS*
SS
-
DD
-
LOA (M)
127.68
LBP (M)
119.80
BEAM (M)
19.60
DEPTH (M)
11.55
SUMMER DRAFT (M)
8.71
WINTER DRAFT (M)
8.53
TROPICAL DRAFT (M)
8.90
GT (MT)
7321.00
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
4112.00
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
13034.08
WINTER DWT (MT)
-
TROPICAL DWT (MT)
13425.08
DISPLACEMENT (MT)
-
LDT (MT)
16582.05
GEAR(S)
CRANE,1 x 5MT
M/E(S)
B&W 6S35MC 5279 HP, 173RPM
M/E POWER (KW)
3883
A/E(S)
-
GENERATOR(S)
4 x 1080KVA AC
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
MAX:15KTS
ECO:13.6KTS
FUEL TYPE
IFO 380,MDO
BUNKER CAPACITY (CBM)
688.95
TANKS CAPACITY (CBM)
SLOPTANK: 1790.74,MDO/MGO:131.68
COMPARTMENT(S)
8
NUMBER OF CARGO HOLDS
16
CARGO CAPACITY98% (CBFT)
435281.48 (WITHOUT SLOPTANK)
CARGO CAPACITY98% (CBM)
12330.92 (WITHOUT SLOPTANK)
COATING/MATERIAL OF HOLD(S)
STAINLESS STEEL
HEATING SYSTEM
STAINLESS STEEL COILED
SACRIFICIAL ANODE
HA-9F / HA-8D
IGS
-
PUMP(S)
CARGO(SCREW):4 x 500/300 CBM/HR
BALLAST(CENTRIFUGAL):1 x 350CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
-
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
BUYERS OFFER
REMARK(S)
DISPLACEMENT(MT):16192.41(WINTER);16971.04(TROPICAL)
SBT(CBM):3951.95
BALLAST TANKS ARE EPOXY COATED
BOILER:1 x 10.48MT/HR
