VESSEL NAME

TNK214

TYPE

OIL/CHEMICAL TANKER

HULL TYPE

DOUBLE HULL

FLAG

DIS

PORT OF REGISTRY

LAESO

BUILT YEAR

2004

BUILT PLACE

CEKSAN SHIPYARD TUZLA, TURKEY

CLASSIFICATION

DNV

CLASS NOTATION

1A1, ICE1B, ESP, EO, VCS-1, TM

SS

-

DD

-

LOA (M)

87.82

LBP (M)

85.01

BEAM (M)

13.39

DEPTH (M)

-

SUMMER DRAFT (M)

6.50

WINTER DRAFT (M)

-

TROPICAL DRAFT (M)

-

GT (MT)

2947.00

PANAMA GT (MT)

-

SUEZ GT (MT)

-

NT (MT)

1270.00

PANAMA NT (MT)

-

SUEZ NT (MT)

-

SUMMER DWT (MT)

4513.00

WINTER DWT (MT)

-

TROPICAL DWT (MT)

-

DISPLACEMENT (MT)

-

LDT (MT)

-

GEAR(S)

1 HOSE HANDLING CRANE SWL 2MT, 1 PROVISION CRANE SWL 0.5MT

M/E(S)

MAN B&W 8L 27/38, 800RPM

M/E POWER (KW)

2720

A/E(S)

2 x VOLVO PENTA TYPE TAMD 165 EACH 400KW

GENERATOR(S)

-

SHAFT GENERATOR(S)

450KW

PROPELLER(S)

MAN B&W CONTROLLABLE PITCH PROPELLER

SPEED /CONSUMPTIONS

13KTS ON 10.5MT/DAY

FUEL TYPE

-

BUNKER CAPACITY (CBM)

-

TANKS CAPACITY (CBM)

MDO:112; MGO:33; BALLAST WATER: 2069

COMPARTMENT(S)

11

NUMBER OF CARGO HOLDS

6

CARGO CAPACITY98% (CBFT)

377449+SLOP TANK: 5867

CARGO CAPACITY98% (CBM)

10693+SLOP TANK: 166

COATING/MATERIAL OF HOLD(S)

EPOXY

HEATING SYSTEM

THE HEATING SYSTEM IS A PRIMARY/SECONDARY SYSTEM, SERVED BY TWO OIL FIRED THERMAL OIL HEATERS

SACRIFICIAL ANODE

-

IGS

YES

PUMP(S)

11 x 175CBM/H ELECTRIC DRIVEN DEEP-WELL PUMPS, FOR CARGO 2 x 50CBM/H ELECTRIC DRIVEN DEEP-WELL PUMP, FOR SLOP TANKS, 1500CBM/H

ONE PUMP FOR SINGLE HOLD OR NOT

-

SIDE THRUSTER(S)

-

INSURANCE

-

CREW

-

ACCOMMODATION

-

INSPECTION

-

DELIVERY

-

PRICE

USD 7.5 MILLION

REMARK(S)

TANK MONITORING AND MEASURING BY SAAB FROM CARGO CONTROL STATION AT BRIDGE. HYDRAULIC REMOTE OPERATED VALVES. CLOSE LOADING(ACC TO SOLAS 74/8 REG 59) BY VAPOUR RETURN 2 x ARPA RADARS JRC TRANSAS ECS JRC GPS JRC AUTOPILOT NAVITRON DEPTH SOUNDER JRC RECORDER NAVTEX JRC NAVTEX RECIVER EUROPEAN TRADE TPC 10.82MT
