VESSEL NAME
TNK246
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL /DOUBLE BOTTOM
FLAG
NORWAY INTERNATIONAL REGISTER
PORT OF REGISTRY
HAUGESUND
BUILT YEAR
1998
BUILT PLACE
NAVAL GIJON S.A. (NAGISA), SPAIN
CLASSIFICATION
LR
CLASS NOTATION
+100A1* CHEMICAL TANKERS SHIP TYPE 1 IN ASSOCIATION WITH A LIST OF DEFINED CARGOES, CR(ST.ST) S.G. 2’1*, ESPE*, IWS*, PCWB6*, PL*, STB(LR)*, +LMG*, UMS*, LNC(AA)* IMO I/II/III
SS
2018-03
DD
-
LOA (M)
148.60
LBP (M)
139.30
BEAM (M)
23.00
DEPTH (M)
12.95
SUMMER DRAFT (M)
9.96
WINTER DRAFT (M)
9.75
TROPICAL DRAFT (M)
10.17
GT (MT)
12184.00
PANAMA GT (MT)
-
SUEZ GT (MT)
12437.00
NT (MT)
5667.00
PANAMA NT (MT)
10244.00
SUEZ NT (MT)
10103.00
SUMMER DWT (MT)
19152.00
WINTER DWT (MT)
18470.00
TROPICAL DWT (MT)
19720.00
DISPLACEMENT (MT)
-
LDT (MT)
6580.00
GEAR(S)
-
M/E(S)
MAN B&W 5S50MC 135KW, MCR 9699BHP 127RPM
M/E POWER (KW)
7238
A/E(S)
3 x B&W HOLEBY 5L23/30H, 890BHP
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
-
SPEED /CONSUMPTIONS
15 KTS
FUEL TYPE
IFO380
BUNKER CAPACITY (CBM)
1075
TANKS CAPACITY (CBM)
FW: 1253
MGO: 90
COMPARTMENT(S)
34
NUMBER OF CARGO HOLDS
34
CARGO CAPACITY98% (CBFT)
700705
CARGO CAPACITY98% (CBM)
19850
COATING/MATERIAL OF HOLD(S)
SOLID STAINLESS STEEL (AVESTA 2205)
HEATING SYSTEM
STEAM HEATING COILS
SACRIFICIAL ANODE
-
IGS
YES, NITROGEN GENERATOR
PUMP(S)
34 SETS, TOTAL 1600CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
BOW THRUSTER, 800 BHP/600KW
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
CHINA
DELIVERY
-
PRICE
USD 10.80 MILLION
REMARK(S)
SBT
FIXED TANK CLEANING MACHINES, 1 OR 3 IN EACH TANK
