VESSEL NAME
TNK258
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
PANAMA
PORT OF REGISTRY
PANAMA
BUILT YEAR
2000
BUILT PLACE
FUKUOKA SHIPBUILDING, JAPAN
CLASSIFICATION
NK
CLASS NOTATION
-
SS
2019-02-02
DD
2017-02-02
LOA (M)
110.00
LBP (M)
103.00
BEAM (M)
18.50
DEPTH (M)
9.60
SUMMER DRAFT (M)
7.46
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
5090.00
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
2472.00
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
8301.00
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
DISPLACEMENT (MT)
-
LDT (MT)
-
GEAR(S)
-
M/E(S)
AKASAKA MITSUBISHI 6UEC37LA 4200BHP 210RPM
M/E POWER (KW)
3134
A/E(S)
3 x DAIHATSU 6DL-16 EACH 480PS 1200RPM
GENERATOR(S)
-
SHAFT GENERATOR(S)
-
PROPELLER(S)
-
SPEED /CONSUMPTIONS
ECO SPEED: LADEN, ABT. 12KTS, ON ABT. 8.2MT IFO380CST/DAY(ME)+ABT. 1.2MT MDO/DAY(GEN)
FUEL TYPE
IFO380CST, MDO
BUNKER CAPACITY (CBM)
-
TANKS CAPACITY (CBM)
-
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
18
CARGO CAPACITY98% (CBFT)
311840
CARGO CAPACITY98% (CBM)
8834
COATING/MATERIAL OF HOLD(S)
SUS 316L STAINLESS STEEL
HEATING SYSTEM
STAINLESS COIL/STEAM HEATING
SACRIFICIAL ANODE
-
IGS
-
PUMP(S)
FRAMO SUBMERGED HYDRAULICALLY-DRIVEN CENTRIFUGAL CARGO PUMPS 18x200CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
-
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
BUYERS OFFER
REMARK(S)
SEGREGATED BALLAST TANK
