VESSEL NAME
TNK195
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
NORWAY
PORT OF REGISTRY
BERGEN
BUILT YEAR
1997
BUILT PLACE
S.E.C.VIAREGGIO ITALY
CLASSIFICATION
DNV
CLASS NOTATION
+1A1 ICE-1A TANKER FOR CHEMICALS AND OIL ESP E0 NAV-O VCS-1 TMON
SS
-
DD
-
LOA (M)
146.06
LBP (M)
135.60
BEAM (M)
21.72
DEPTH (M)
10.75
SUMMER DRAFT (M)
8.36
WINTER DRAFT (M)
8.19
TROPICAL DRAFT (M)
8.54
GT (MT)
9383.00
PANAMA GT (MT)
-
SUEZ GT (MT)
9349.27
NT (MT)
4616.00
PANAMA NT (MT)
7920.00
SUEZ NT (MT)
7623.00
SUMMER DWT (MT)
13843.00
WINTER DWT (MT)
13362.00
TROPICAL DWT (MT)
14325.00
DISPLACEMENT (MT)
19520.00
LDT (MT)
-
GEAR(S)
CRANES, 2 x 5MT, OUTREACH: 1M
M/E(S)
WARTSILA 6L46 8565 BHP
M/E POWER (KW)
6391KW
A/E(S)
-
GENERATOR(S)
3 GENERATORS
SHAFT GENERATOR(S)
1 SHAFT GENERATOR
PROPELLER(S)
CPP
SPEED /CONSUMPTIONS
BALLAST: 14.5KTS, 27MT (IFO) + 1MT (MGO)
LADEN: 14.5 KTS, 27.5MT(IFO) + 1MT (MGO)
FUEL TYPE
MAIN ENGINE: IFO380
GENERATOR: MGO
BUNKER CAPACITY (CBM)
822.4
TANKS CAPACITY (CBM)
SLOP TANK: 314, SBT: 544.8, MDO/MGO: 120.8
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
27
CARGO CAPACITY98% (CBFT)
547750
CARGO CAPACITY98% (CBM)
15517
COATING/MATERIAL OF HOLD(S)
STAINLESS STEEL
HEATING SYSTEM
STAINLESS STEEL COILS (HOT WATER)
SACRIFICIAL ANODE
ZNIC
IGS
YES
PUMP(S)
CARGO PUMP (CENTRIFUGAL): 16 x 240CBM/HR, 7 x 200CBM/HR, 4 x 150CBM/HR, 3 x 80CBM/HR
STRIPPING PUMP (CENTRIFUGAL): 30 x 40CBM/HR
BALLAST PUMP (CENTRIFUGAL): 2 x 400CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
BOW THRUSTER: 1 x 750BHP (559.27KW), STERN THRUSTER:1 x 600BHP(447.42KW)
INSURANCE
POLLUTION LIABILITY COVERAGE: 1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
USD 8.8 MILLION
REMARK(S)
DISPLACEMENT(MT): 19039 (WINTER), 20002 (TROPICAL)
BALLAST TANKS ARE COATED WITH EPOXY
SBT
