VESSEL NAME
TNK189
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
SINGAPORE
PORT OF REGISTRY
SINGAPORE
BUILT YEAR
1994
BUILT PLACE
HITACHI ZOSEN SINGAPORE LIMITED SINGAPORE
CLASSIFICATION
NK
CLASS NOTATION
NS*(TANKER, OILS-FLASHPOINT BELOW
60 DEG C) (ESP) MNS*
SS
-
DD
-
LOA (M)
119.98
LBP (M)
111.60
BEAM (M)
19.00
DEPTH (M)
12.10
SUMMER DRAFT (M)
9.02
WINTER DRAFT (M)
8.81
TROPICAL DRAFT (M)
9.19
GT (MT)
7354.00
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
3067.00
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
12122.00
WINTER DWT (MT)
11738.00
TROPICAL DWT (MT)
12507.00
DISPLACEMENT (MT)
15634.00
LDT (MT)
-
GEAR(S)
CRANE, 1 x 5MT, CENTRE, OUTREACH 4.5M
M/E(S)
2 x AKASAKA DM30R 3000BHP
M/E POWER (KW)
2 x 2239
A/E(S)
-
GENERATOR(S)
3 x 308KW 415V 50HZ A.C.
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP
SPEED /CONSUMPTIONS
12
FUEL TYPE
IFO
BUNKER CAPACITY (CBM)
550.23
TANKS CAPACITY (CBM)
SLOP TANK: 2196, SBT: 5861.08, MDO/MGO: 174.84
COMPARTMENT(S)
3
NUMBER OF CARGO HOLDS
-
CARGO CAPACITY98% (CBFT)
305190
CARGO CAPACITY98% (CBM)
8642
COATING/MATERIAL OF HOLD(S)
EPOXY
HEATING SYSTEM
316LSTAINLESS STEEL COILES (THERMAL LIQUID HEATING)
SACRIFICIAL ANODE
-
IGS
-
PUMP(S)
CARGO (SCREW): 2 x 1200CBM/HR, 1 x 400CBM/HR
STRIPPING (SCREW): 1 x 100CBM/HR
BALLAST (SCREW): 1 x 400CBM/HR
ONE PUMP FOR SINGLE HOLD OR NOT
YES
SIDE THRUSTER(S)
-
INSURANCE
POLLUTION LIABILITY: USD 1 BILLION
CREW
-
ACCOMMODATION
-
INSPECTION
SINGAPORE
DELIVERY
SINGAPORE
PRICE
USD 5.8 MILLION
REMARK(S)
DISPLACEMENT (MT): 15250(WINTER), 16019(TROPICAL)
SBT
BALLAST TANK AND SLOP TANK ARE COATED WITH EPOXY
