VESSEL NAME
TNK713
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL/DOUBLE BOTTOM
FLAG
PANAMA
PORT OF REGISTRY
PANAMA
BUILT YEAR
2006
BUILT PLACE
CHINA
CLASSIFICATION
LR
CLASS NOTATION
✠100A1 Double Hull and Chemical Tanker, Ship Type 2, ESP, LI Ice Class 1A FS at a Draught of 9.07m. Max/Min Draughts: Forward: 9.07 / 5.10m., Aft: 9.07 / 6.50m. Power Required: 5,830kW, Power Installed: 6,300kW
SS
2026-07
DD
2026-07
LOA (M)
144.05
LBP (M)
133.8
BEAM (M)
23
DEPTH (M)
12.4
SUMMER DRAFT (M)
8.9
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
11935
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
5137
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
16664
WINTER DWT (MT)
TROPICAL DWT (MT)
-
DISPLACEMENT (MT)
-
LDT (MT)
-
GEAR(S)
-
M/E(S)
MAN 6l48/60b MCR 9789 HP 500 RPM
M/E POWER (KW)
-
A/E(S)
-
GENERATOR(S)
1x1,020 KW, 2x680 KW
SHAFT GENERATOR 1x1,500 KW
SHAFT GENERATOR(S)
-
PROPELLER(S)
CPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
-
BUNKER CAPACITY (CBM)
-
TANKS CAPACITY (CBM)
-
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
12
CARGO CAPACITY98% (CBFT)
681855
CARGO CAPACITY98% (CBM)
19316
COATING/MATERIAL OF HOLD(S)
EPOXY
HEATING SYSTEM
-
SACRIFICIAL ANODE
-
IGS
YES
PUMP(S)
12 x 300 CBM/H
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
-
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
15 M
REMARK(S)
BWTS; SBT; COW
